Touptek
Touptek SkyEye 62AC
£2,850.00
Liquid error (snippets/product-blocks line 110): divided by 0
Off
Unit price
/
SkyEye 62 AM
These exceptional cameras feature the very latest super-high resolution, high sensitivity IMX455 Sony CMOS sensor. They provide wonderful image quality and are widely used in astronomy, scientific research and in industry. They are cooled and deliver ultra-low readout noise and zero amp-glow - a truly exceptional performance. This camera is available in colour (*-AC) and (*-AM) monochrome formats.
These exceptional cameras feature the very latest super-high resolution, high sensitivity IMX455 Sony CMOS sensor. They provide wonderful image quality and are widely used in astronomy, scientific research and in industry. They are cooled and deliver ultra-low readout noise and zero amp-glow - a truly exceptional performance. This camera is available in colour (*-AC) and (*-AM) monochrome formats. (just specify colour when ordering if that is the version you prefer)
FEATURES:
Full frame Sony CMOS sensor
High sensitivity
Ultra-low noise
Support low noise mode/ high frame rate mode
16/12 bit(SkyEye62AC, SkyEye 62AM) or 14/12 bit ADC(SkyEye24AC)
512 Mbyte memory onboard
Hardware ROI
Long exposure time(0.1ms~3600s)
USB3 port ensuring high speed data transmission;
-35degC below ambient under short exposure/ -35degC under long exposure time (> 1s)
Support HCG mode/ LCG mode
Zero amp-glow
Sensor tilt adjustment
M54 x 0.75 mount
Native ASCOM/WDM driver for easy connection with 3rd party astrophotography software
ToupSky for Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit), OSx(Mac OS X), Linux
Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc.)
DATASHEET:
|
Order Code
|
Sensor & Size(mm)
|
Pixel(μm)
|
G Sensitivity
Dark Signal
Dynamic Range
SNR(max)
|
FPS/Resolution
|
Binning
|
Exposure
|
|
SkyEye62AM
SEYM1062000A
|
61M/IMX455(M)
2.7"(35.98x23.99)
Full Frame
|
3.76x3.76
|
871mv with 1/30s
0.039mv with 1/30s
88.3dB
47.1dB
|
6.2@9568x6380(16bit)
18.8@4784x3190
55@3184x2124
|
1x1,
2x2,
3x3
|
0.1ms~3600s
|
|
SkyEye62AC
SEYP1062000A
|
61M/IMX455(C)
2.7"(35.98x23.99)
Full Frame
|
3.76x3.76
|
484.5mv with 1/30s
0.039mv with 1/30s
85.8dB
47.0dB
|
6.2@9568x6380(16bit)
18.8@4784x3190
55@3184x2124
|
1x1,
2x2,
3x3
|
0.1ms~3600s
|
|
SkyEye24AC
SEYP1024000A
|
24M/IMX410(C)
2.7"(36.02x24.00)
Full Frame
|
5.94x5.94
|
573mv with 1/30s
0.037mv with 1/30s
87.3dB
50.2dB
|
16@6064x4040(14bit)
38.8@3024x2012
114.6@2016x1312
|
1x1,
2x2,
3x3
|
0.1ms~3600s
|
OTHER SPECIFICATIONS
|
Spectral Range
|
380-690nm (with IR-cut Filter) or 350-1050nm(with Double Side AR Coating Protect Window)
|
|
White Balance
|
ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor
|
|
Color Technique
|
Ultra-FineTM Color Engine/NA for Monochromatic Sensor
|
|
Capture/Control SDK
|
Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc);
|
|
Recording System
|
Still Picture and Movie
|
|
Cooling System*
|
Two-stage TE-cooling System 30-35 °C below Ambient Temperature
|
|
Operating Environment
|
|
Operating Temperature(in Centidegree)
|
-10~ 50
|
|
Storage Temperature(in Centidegree)
|
-20~ 60
|
|
Operating Humidity
|
30~80%RH
|
|
Storage Humidity
|
10~60%RH
|
|
Power Supply
|
External Power Adapter, DC12V, 3A
|
|
Software Environment
|
|
Operating System
|
Microsoft® Windows® XP / Vista / 7 / 8 / 10 / 11 (32 & 64 bit)
OSx(Mac OS X)
Linux
|
|
PC Requirements
|
CPU: Equal to Intel Core2 2.8GHz or Higher
|
|
Memory:2GB or More
|
|
USB Port: USB2.0 High-speed Port
|
|
The largest display you can afford!
|
|
CD-ROM/USB port for software
|
