Light and small
Weighs only 188 grams 10cm x 7.2cm x 2.4cm
Easy installation
M6 threaded hole and M4 threaded holes at the bottom
5V power supply
Built-in 12V-5V step-down module
Provides continuous current up to 5A Comes with 6A self-recovery fuse to prevent overcurrent
Electrostatic protection
All USB ports are equipped with ±20kV ESD for stability in dry weather
Abundant DC output ports
Provides you Everything
Port 9 is an Always On DC output, which is suitable for equipment that needs to be powered on all the time such as your computor.
Ports 1-3 are PWM outputs , which allow mannual or auto control of your dew heaters.
Ports 4-8 are five DC outputs , suitable for power supply for your CCDs , rotators , focusers , etc .
Dew heater/Switch Mode can be switched on your demand
If you do not need a dew heater or only need one dew heater, ports 1-3 can also be set to Switch Mode , which works same as ports 4-8.
High current
+
5V power supply
Meet the power needs of various equipment
Dual gold-plated DC5.5x2.5mm input ports support a maximum current of 16A (maximum 10A when powered by a single port) Ports 1-4 each provides up to 6.5A
Ports 9 provides up to 8A Ports 5-8 provides up to 6.5A in total
When 12V power supply is connected, all USB outputs can provide 5V power supply Total output up to 5A Meet the needs of 5V powered devices such as 5V dew heaters and focusers
USB On/Off
9 USB ports can be switch on/off independently (power+data)
Device debugging, COM port refresh, device restart...
No longer need to restart your computer frequently!
Built-in Power Sensor
Real-time visual monitoring of input voltage and current
Help you know if the device is working properly
Environment Sensor
Optional DHT22 temperature and humidity sensor and DS18B20 temperature probe Can also get data from WandererWeather Mini weather station Provides you with various auto dew heater control mode !
Powerful customization features
Switch Mode, switch name, USB device name...
Sensor type，dew heater control mode...
Technical Specification
