Askar FRA400C APO Astrograph - Dark Clear Skies

Askar

FRA400C

Bin Location: G-Front

£895.00

Quantity

Askar FRA400C APO Astrograph

The Askar FRA400C is a versatile quintuplet APO astrograph designed for both astrophotography and visual use. With a 72 mm aperture, 400 mm focal length at f/5.6, and ED glass elements, this telescope delivers crisp, flat-field images across a large 44 mm full-frame sensor.

Key Features

  • Aperture: 72 mm
  • Focal Length: 400 mm (f/5.6)
  • Optical Design: Quintuplet APO (Petzval)
  • Image Circle: 44 mm (full-frame coverage)
  • Focus: 2.5″ dual-speed rack-and-pinion focuser
  • Back Focus: 140 mm
  • Use Case: Wide-field astrophotography and observation

Why Choose the FRA400C?

The FRA400C’s Petzval optical design eliminates the need for a separate field flattener, ensuring sharp stars across the entire frame. This makes setup quicker and easier, saving valuable imaging time under the night sky.

Ideal For

  • Wide-field imaging of nebulae and star clusters
  • Full-frame astrophotography
  • Astrophotographers seeking a compact, flat-field refractor

The Askar FRA400C is a superb balance of portability, optical performance, and convenience, making it an excellent choice for beginners and advanced imagers alike.

Product introduction

长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体
长友气体

Specifications

FRA400C Parameters

Aperture size

72mm

Focal length

400mm

Focal ratio

f/5.6

Objective lens

Quintuplet dual ED air-spaced APO

Format specifications

44mm

Aperture blades

17 pieces

Graded Aperture

f/5.6-f/22

Closest Focus Distance

5m

Focusing mode

Manual focus

Filter Diameter

M82

Total length

370mm (inclulding dew shield); 420mm (without dew shield)

OTA weight

2.68kg

Total weight (including handle & dovetail plate)

3.18kg

Rear-end adapter

M72/M54/M48(with M48×0.75 filter thread)

Rear-end connection distance

Support 50-60mm range (Recommended connection length is 55mm)

Standard package items

1.25inch/2inch adapter,a manual



Product Size Diagram

长友气体长友气体长友气体

FRA400C AFkit Electronic Focuser Assembly Diagram

长友气体长友气体

Optical Path Diagram

长友气体

Spot Diagram

长友气体

Longitudinal Aberration

长友气体

Video

Images

长友气体
The Shark Nebula LRGB  |  Mihail Mamchurov  |  Askar FRA400 + ZWO ASI2600MM Pro
长友气体
Cesar Cobra  |  IC 4592  |  Askar FRA400 + ZWO ASI294MC Pro
长友气体
Laurent Marzec  |  SH2-296  |  Askar FRA400 + ZWO ASI2600MC Pro
