Lunt LS1.25HW 1.25" Herschel Wedge – Premium White-Light Solar Filter for Refractors

SKU: 0558211
EAN: 4007922035284

Observe the Sun in Unmatched Detail and Complete Safety

The Lunt LS1.25HW Herschel Wedge is a high-performance solar diagonal designed for White-Light solar observation and imaging with refractor telescopes up to 102mm aperture. Unlike front-mounted solar filters, the Herschel wedge filters the Sun’s light just before the eyepiece or camera, delivering superior contrast and resolution to reveal fine details like sunspots and solar granulation.

Key Features

• ✔️ Designed for refractor telescopes up to 102mm aperture
• ✔️ 1.25" telescope and eyepiece connection
• ✔️ Built-in ND3.0 neutral density filter – factory installed
• ✔️ 90° star diagonal-style housing for ergonomic viewing
• ✔️ Fully enclosed body with integrated heat trap
• ✔️ No escaping stray light – completely safe for visual use
• ✔️ Excellent choice for high-contrast White-Light solar imaging

Safe, Durable & Reliable Solar Viewing

About 95% of the Sun’s light is suppressed by the internal ceramic prism. The remaining light is further reduced by the pre-installed ND3.0 filter. The fully enclosed housing and integrated heat trap ensure that no stray light escapes, making this wedge one of the safest ways to view the Sun.

Unlike foil filters that can rip or detach, the Lunt Herschel Wedge is built for reliability and long-term safety. It’s the preferred choice for astronomers who demand both safety and performance in solar observation.

Usage Notice

Only for use with refractor telescopes without rear corrector lenses.
Do not use with reflectors or catadioptrics – internal components may be damaged by heat.

Brightness Adjustment

The wedge produces polarised light. You can adjust image brightness by adding a standard polarising filter to your eyepiece or camera adapter (not included). We recommend the BRESSER 1.25" polarising filter (item no. 4946464).

Specifications

• Connection to telescope: 1.25"
• Connection to eyepiece: 1.25"
• Housing: 90° star diagonal style
• Eyepiece view direction: 90° inclined
• Solar filter type: White-Light
• Material: Aluminium
• Weight: 0.23 kg
• Dimensions (LxWxH): 90 x 40 x 100 mm
• Colour: Black
• Warranty: 5 Years

What's Included

• ✔️ Lunt 1.25" Herschel Wedge
• ✔️ Factory-installed ND3.0 filter
• ✔️ Aluminium transport case
• ✔️ Instruction manual

Trusted by solar astronomers worldwide for quality and safety.
